Features
Advanced multi-function indicator, suitable for the most complex industrial weighing applications
Wide range of Serial, Ethernet and optional FieldBus interfaces allows simple, low cost connection to operating networks and peripheral devices
Weighing, counting, checkweighing, recipe/ filling ( 100 recipes/ 20 steps) , totalising, peak hold, remote display, in-motion weighing, comprehensive weighbridge operations, multi-level pack runs and weight conversion applications as standard
Alpha-numeric keypad ( plus PS/ 2 keyboard interface) features 5 function keys and 300 PLUs for easier operation of most popular applications
Up to 16 fully flexible inputs and outputs – can replace a PLC for a simpler, more reliable system
Specifications
Graphical display, presents information in the most relevant format
Up to 4 serial interfaces, selectable for RS232, RS485, RS422 or 4-20mA Current Loop, Ethernet TCP/ IP as standard, plus optional DeviceNet, ModBus TCP, ProfiBus DP, Ethernet IP and ControlNet
Connects to a wide range of analogue load cells – maximum 16 load cells with optional second scale support
Optional electronic archiving
IP54 rated, dust resistant plastic case, suitable for desk, wall or pole mounting
Approvals
Trade approved for 10, 000 divisions
